M5Stack PaperColorBring vibrant, always-on displays to your next IoT innovation without draining power.

M5Paper Color ESP32S3 Dev Kit

The M5Paper Color ESP32S3 Dev Kit is a powerful development board featuring a stunning 4-inch E Ink Spectra 6 full-color e-paper display with 600x400 resolution. Built around the ESP32-S3R8 dual-core processor with 16MB Flash and 8MB PSRAM, this ultra-low-power device combines vibrant color display technology with comprehensive IoT capabilities, making it ideal for battery-powered smart displays and interactive terminals.

Product Highlights

• Full-Color E-Paper Display: 4-inch SPECTRA 6 eInk screen with 400x600 resolution delivers paper-like readability with vibrant colors and zero power consumption for static images
• ESP32-S3R8 Performance: Dual-core Xtensa LX7 processor up to 240MHz with 16MB Flash and 8MB PSRAM for complex applications
• Complete Audio System: ES8311 audio codec with MEMS microphone, AEC echo cancellation, and 1W speaker for voice interaction
• Extended Battery Life: 1250mAh battery with M5PM1 power management achieves 92.53µA standby consumption
• Rich Sensor Integration: Built-in SHT40 temperature/humidity sensor and RX8130CE real-time clock
• Wireless Connectivity: 2.4 GHz Wi-Fi support for seamless IoT integration

Use Cases

• Smart Digital Photo Frame: Display vibrant color photos with months of battery life between charges
• Electronic Signage: Create eye-catching retail displays, menu boards, and information panels that update remotely
• Voice Interaction Terminal: Build smart assistants and control panels with integrated microphone and speaker
• Environmental Monitor: Track and display temperature, humidity, and other sensor data with always-visible readings
• Art Display Installation: Showcase digital artwork with museum-quality color reproduction and paper-like texture

Target Audience

Perfect for IoT developers, makers, and businesses seeking ultra-low-power color display solutions for smart home devices, industrial panels, retail signage, and interactive kiosks.
